Ruby Modularity

Published 2023-06-03.
Time to read: 3 minutes.

This page is part of the ruby collection.

The Ruby language allows modules and classes to be redefined and/or enhanced at runtime. This may seem strange to programmers who work with other computer languages.

Modularity

Similar to the Python language, Ruby classes and modules are mutable. Class and module methods are just attributes of the enclosing class or module, and they can be changed. New methods can be added to a pre-existing module or class.

Modifying Ruby libraries in this way is called monkey patching, and this powerful feature can be dangerous.

However, for your own code, reopening your own modules and classes to add new methods and variables can be a terrific way to write in a modular fashion, and this code is generally quite maintainable.

Case Study: Git_tree

My git_tree Ruby gem takes advantage of mutable modules to provide a simple and flexible mechanism for organizing code in a manageable manner.

Git_tree mostly consists of one module, GitTree, that contains common code for all the git-tree subcommands (git-tree-evars, git-tree-exec, and git-tree-replicate).

lib/git_tree.rb

module GitTree
  def self.directories_to_process(root)
    # implementation
  end
end

In the above code, the self. prefix for the method name marks this method as being a module-level method. Module methods can be invoked without having to include or extend the containing module.

When a subcommand is launched, the GitTree module is re-opened, and methods are added that are specific to that subcommand, then the code is executed.

The above GitTree module is re-opened in the following 3 files. In each of them:

The require_relative statement reads the original definition of the GitTree module, shown above.
The module GitTree statement re-opens the module definition and adds new methods to it for the subcommand that the file implements. Two kinds of methods are common to each subcommand:
1. command_xxx methods contain the top-level logic for the xxx subcommand.
2. help_xxx methods display the help message for the xxx subcommand.

Notice that no Ruby classes are used for modularity purposes.

lib/git_tree_evars.rb

require_relative 'git_tree'

module GitTree
  def self.command_evars(root)
    # implementation
  end

  def self.help_evars(msg = nil)
    # implementation
  end

  # Other methods also
end

lib/git_tree_exec.rb

require_relative 'git_tree'

module GitTree
  def self.command_exec(root)
    # implementation
  end

  def self.help_exec(msg = nil)
    # implementation
  end

  # Other methods also
end

lib/git_tree_replicate.rb

require_relative 'git_tree'

module GitTree
  def self.command_replicate(root)
    # implementation
  end

  def self.help_replicate(msg = nil)
    # implementation
  end

  # Other methods also
end

Debug Stubs

Stubs are used for debugging command-line invocations because it is awkward to repeatedly compile-edit-debug installed gems. There is one debug stub for each of the three git-tree subcommands. The debug stubs are not included in the gem.

test/git_tree_evars.rb

require_relative '../lib/git_tree_evars'

GitTree.command_evars

test/git_tree_exec.rb

require_relative '../lib/git_tree_exec'

GitTree.command_exec

test/git_tree_replicate.rb

require_relative '../lib/git_tree_replicate'

GitTree.command_replicate

The Visual Studio Code launch.json entries for debugging are also simple. Each of the above three stubs can be debugged separately.

.vscode/launch.json

{
  "version": "0.2.0",
  "configurations": [
    {
      "args": [ "$jekyll_img $jekyll_pre", "version" ],
      "name": "Debug git-tree-exec",
      "type": "Ruby",
      "request": "launch",
      "program": "${workspaceRoot}/test/git_tree_exec.rb"
    },
    {
      "args": [ "$work" ],
      "name": "Debug git-tree-evars",
      "type": "Ruby",
      "request": "launch",
      "program": "${workspaceRoot}/test/git_tree_evars.rb"
    },
    {
      "args": [ "$work" ],
      "name": "Debug git-tree-replicate",
      "type": "Ruby",
      "request": "launch",
      "program": "${workspaceRoot}/test/git_tree_replicate.rb"
    },
  }
}

😁

Simple, elegant, flexible and easy to understand modularity.
